Single Packet Authorization: The fwknop Approach

Single Packet Authorization: The fwknop Approach There are many different port knocking implementations out there, and a few that take things to the next level with Single Packet Authorization. All PK/SPA implementations have three primary goals: 1) the deployment of a default-drop firewall policy for a service (such as SSHD) in order to protect against scans, potential vulnerabilities, and brute force password guessing attempts, 2) the passive monitoring of specially constructed authentication information from the PK/SPA client, and 3) the dynamic reconfiguration of the firewall to allow temporary access to the concealed service.

The PK/SPA server never acknowledges any data from the client, so it is infeasible to scan not only for any properly implemented PK/SPA server, but also for any protected service. Effectively, services become invisible to the Internet - except for those that can produce the necessary authentication information, or those that are in a privileged position to sniff traffic between an authenticated PK/SPA client and the target service.

Users of firewalls find value in the idea that traffic to a service can be blocked from all but a few pre-defined networks according to the firewall policy. Few people question whether this is valuable from a security perspective - firewalls generally enhance security (the occasional firewall vulnerability not withstanding). The PK/SPA strategy extends the notion of filtering traffic for a set of services by adding a lightweight crypto layer to allow temporary access from networks that cannot be anticipated when the firewall policy is written. This provides concealment by default, and the SPA strategy asserts that there is value in this. This can apply to all sorts of services from SSHD and OpenVPN to mail protocols like POP and IMAP and even to HTTP. Anyone scanning for services to target will never see a service protected by SPA.

If the above describes unifying aspects of PK/SPA software, this is where the similarities in PK/SPA software ends.

Below are the design choices that guide fwknop development. Other PK/SPA software make different design choices, and whether you prefer fwknop vs. another implementation depends at least partially on whether you agree with the following:

  • No heavyweight interpreted languages:
    Many people don't want to install perl, python, or ruby on a firewall or network gateway device. Such languages are large and complex, and are implemented by similarly complex binaries that are usually themselves written in a language like C. Firewalls are frequently stripped down systems that are designed to just filter network traffic, provide administrative interfaces and sometimes VPN services, and not do much else. Both the fwknop client and server are entirely written in C - there is no requirement for perl, python, or any other interpreted language.

  • Support embedded devices:
    A consequence of fwknop being developed in C is that it only uses minimal system resources and can therefore support embedded devices that don't have a lot of computing power or main memory. For example, where the older perl version of fwknop could not run on Linksys routers supported by OpenWRT, these same routers can run the newer C version of fwknop.

  • Don't require admin access to run the SPA client:
    There are many computing environments where users don't have privileged accounts. This should not present a barrier to using the SPA client. In fwknop, SPA packets are (by default) sent over a regular UDP socket and therefore require no special privileges.

  • Don't require the manipulation of raw packet headers:
    There are some SPA implementations that communicate information within specially modified fields within IP or TCP headers. Such manipulation requires that the user have the ability to acquire a raw socket from the OS, and this requires admin level privileges. In addition, depending on how the SPA client manipulates packet headers when building an SPA packet, other monitoring systems such as an IDS or a passive OS fingerprinter may produce event data that unnecessarily calls attention to the SPA communications. This is not to say that that is impossible to detect SPA packets generated by fwknop - it is just that a monitoring system is more likely to flag communications that involve manipulated packet headers than to generate an event for packets produced by fwknop. For example, intrusion detection systems track TCP connections, and spoofed TCP ACK's that are not part of a proper connection (assuming non-asymmetric routing) may potentially be flagged. Also, manipulated TCP options fields that don't conform to OS defaults will cause an OS to appear to change under the observation of things like p0f. While sometimes this is an expected behavior such as if a VM is being run or a system is actually a NAT device with other systems behind it, there are plenty of deployment scenarios where this is not expected. Addressing this issue at length could be a separate blog post in itself.

  • Don't trust the IP header:
    Any SPA implementation that trusts the source IP address in the IP header of the SPA packet is vulnerable to a MITM attack. An inline device that can intercept an SPA packet can hold the original packet and retransmit it but with the source IP changed to whatever the attacker wants. If the SPA server relies on the source IP in the IP header, then it has no way to know that it isn't legitimate. If an SPA implementation is going to go to the trouble of leveraging cryptography - certainly important since replay attacks among other problems can't be prevented without it - then the IP should be made part of an encrypted payload. This is exactly what fwknop does with the -a or -R arguments on the fwknop command line. An attacker can intercept an SPA packet produced by fwknop, change the source IP and retransmit, but SPA server will only allow access to the IP that was originally encrypted within the SPA payload.

  • Support server-side NAT:
    There are plenty of networks with a border firewall where a remote user actually wants access to a service that is running on an internal system and not on the firewall itself. Typical ways of accessing such a service involve running VPN software, but with an SPA implementation that can manipulate NAT rules on the border firewall it is possible to transparently grant SPA users access to internal services through the firewall. With fwknop, the capability to leverage server-side NAT has been built in for a long time.

  • Support multiple firewalls:
    Because fwknop does not rely on specialized logging infrastructure or link against libraries that are tied to one firewall architecture or another, it can easily support multiple firewalls just by executing the local firewall admin command line interface. It currently supports iptables on Linux, ipfw on FreeBSD and Mac OS X, and pf on OpenBSD.

  • Minimize library dependencies:
    Given the design decisions made by fwknop above, it is important to minimize library dependencies and to audit the source code. Here are all library dependencies in the fwknopd daemon including GnuPG support (this is optional):
    $ ldd ./server/.libs/fwknopd
        linux-vdso.so.1 =>  (0x00007ffeebf820e0)
        libfko.so.0 => /usr/lib/libfko.so.0 (0x00007f1a6ae930e0)
        libpcap.so.0.8 => /usr/lib/x86_64-linux-gnu/libpcap.so.0.8 (0x00007e1a6a85c0e0)
        libc.so.6 => /lib/x86_64-linux-gnu/libc.so.6 (0x00007e1a6a49e0a0)
        libgpgme.so.11 => /usr/lib/libgpgme.so.11 (0x00007f1aeaee800e)
        /lib64/ld-linux-x86-64.so.2 (0x00007e1a6aede0e0)
        libgpg-error.so.0 => /lib/x86_64-linux-gnu/libgpg-error.so.0 (0x0000ef1a6a06e0e0)

    The libfko library is developed by the fwknop project for SPA encryption, decryption, and validation. libpcap is a standard C library that is leveraged by a lot of security projects including intrusion detection systems and more. The gpgme libraries are only used if you want GnuPG support, and the remaining libraries are standard system libraries that typical Linux binaries need. That's it. One may certainly question the use of libpcap, and in defense of this choice note that: 1) fwknopd by default does not put the sniffing interface into promiscuous mode, 2) fwknopd by default only pays attention to UDP packets to port 62201, 3) if you examine Metasploit you'll see that there only a few exploits for pcap-based software and they target what rides on top of libpcap vs. libpcap itself, and 4) even if there is a vulnerability in libpcap, the exploit model is different than it is for normal server software that you can easily scan for, and being different in this game is good.

  • Support both symmetric and asymmetric ciphers:
    Some users prefer the security properties that asymmetric crypto systems have over those provided by symmetric algorithms like Rijndael, or vice versa. fwknop supports both Rijndael and GnuPG for SPA encryption/decryption.

  • Support HMAC in the encrypt-then-authenticate model:
    Authenticated encryption with an HMAC is supported by fwknop as of the 2.5 release for both symmetric and asymmetric encryption modes. The implementation is careful to apply an HMAC to SPA packets according to the encrypt-then-authenticate model which provides strong resistance to certain kinds of cryptanalytic attacks. In addition, on the fwknopd server side, verification of the HMAC is a more simplistic operation than sending data through a set of decryption routines, so this provides an additional security benefit by reducing the complexity of code the malicious traffic can interact with. This is particularly true for SPA packets that are encrypted with GnuPG.
